The Daikin DAQ12033 split air handler is an indoor unit designed to work in tandem with an outdoor air conditioner or heat pump as part of a split HVAC system. The primary function is to circulate conditioned air—either heated or cooled throughout a commercial space via a network of ducts. Built for high-capacity performance, these air handlers are compatible with zoning systems to ensure even air is distributed and enhance energy efficiency. The Daikin DAQ12033 commercial air handler can be tailored to meet the specific demands of different building layouts, making them an essential component of reliable and flexible HVAC solutions. The Daikin DAQ12033 commercial indoor air handler is made of heavy gauge, reinforced galvanized steel as well as insulated with a fiberglass blanket for temperature control as well as noise level dampening. All models feature a factory installed thermal expansion valve
Daikin 10 Ton Multi-Position Commercial Air Handler - 208/230V 3 Phase - R32 | |
---|---|
SKU | DAQ12033 |
Weight (in lbs) | 430.000000 |
Brand/Manufacturer | Daikin |
Replaces | DAX12043 |
Cooling BTU | 90,000 BTU |
Blower Motor | Multi Speed - PSC |
Drive Type | Belt |
Maximum CFM | 4000 |
Refrigerant | R32 |
Liquid Line | 3/8" (2) |
Suction Line | 1 1/8" (2) |
Electrical | 208 / 240 V. 3 Phase 60 Hz |
Phase | Three Phase |
Min. Breaker Size | 7.5 |
Tonnage | 10 Ton |
Height | 60.5" |
Width | 48.25" |
Depth | 24" |
Warranty | 5 Years with Online Registration |
