MRCOOL - DIY 5th Gen Easy Pro - 1 Ton / 12,000 BTU Ductless Mini Split Air Conditioner & Heat Pump - 19.5 SEER2 - R454B - 115V

by MRCOOL
SKU EZPRO-12-HP-11516D-O
PRICE MATCH GUARANTEE*: Found A Better Price? We'll Beat It! 877-606-9202 *Excludes ACIQ and MRCOOL Products.
EASY RETURNS: 30 Days Return Policy*
NO SALES TAX IN 48 STATES!
FREE SHIPPING: Free Shipping On Most Products!
TRADE & VOLUME DISCOUNTS: Call / Email or Chat for Details!

ADD TO CART FOR INSTANT SAVINGS!

$1,649.00
  • Amazon
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • Shop Pay
  • Visa

The newly released 5th Generation of the MRCOOL Easy Pro® DIY 12K BTU Ductless Mini-Split Heat Pump System is easy to install and is capable of effectively heating and cooling a space of 550 square feet, this easy-to-install unit also includes the convenient 16 foot pre-charged line set, with Fast Connection® fittings.

What's Included

  • 1 x MRCOOL DIY 12K Easy Pro 5th Gen Condenser - EZPRO-12-HP-C-11516D-O
  • 1 x MRCOOL DIY 12K Easy Pro 5th Gen Air Handler -  EZPRO-12-HP-WMAH-115D-O
  • 1 x 16 ft. 1/4 x 3/8 Line Set - DIY16-1438-O
  • 1 x MRCOOL Remote Control - 17317000A63435

Features

  • DIY Installation: Includes a 16-foot pre-charged Fast Connection line set, allowing for quick and easy setup without special tools or equipment.
  • Smart Controls: Equipped with the SmartHVAC WiFi Control Module, compatible with Amazon Alexa and Google Assistant, enabling remote operation via smartphone or voice commands.
  • Energy Efficiency: Achieves a SEER2 rating of 19.5 and HSPF2-4 of 9.3, ensuring cost-effective performance year-round.
  • Quiet Operation: Indoor unit operates as low as 17.5 dB(A), providing a peaceful environment.
  • Durable Design: Features a Gold Fin condenser coating for corrosion resistance, ideal for coastal and high-humidity areas.
  • Low Ambient Cooling: Capable of cooling in outdoor temperatures as low as 5°F, suitable for server rooms and greenhouses.
  • Additional Features: Includes Follow Me function, Sleep Mode, Auto Mode, Timer Mode, and refrigerant leakage detection for enhanced comfort and safety.

Specifications

Condenser Specifications:

BRAND NAME MRCOOL
SERIES EasyPro 5th Gen
MODEL EZPRO-12-HP-C-11516D-O
GTIN 840255586733
UPC 840255586733
UNIT TYPE Mini-Split
EQUIPMENT TYPE Condenser
SHORT DESCRIPTION EasyPro 5th Generation 12k BTU 115V Condenser
SEER2 19.5
EER2 9
HSPF2-4 9.3
HSPF2-5 7
TONNAGE 1
COOLING CAPACITY (BTU) 12000
HEATING CAPACITY (BTU) 12000
VOLTAGE (V) 115
PHASE 1
CYCLE 60
MAX FUSE BREAKER (A) 20
MIN CIRCUIT AMPACITY (A) 19.5
COLOR White
ZONE CAPACITY 1
REFRIGERANT TYPE R-454B
REFRIGERANT VOLUME (OZ) 21.52
DECIBEL RATING HIGH (DBA) 54
INVERTER DC
MIN AMBIENT COOL (F) 5
LINESET INCLUDED Yes
LINE SET LENGTH 16ft
MAX LINESET LENGTH (FT) 82
LIQUID LINE SIZE 1/4
SUCTION LINE SIZE 3/8
COMPRESSOR MOTOR TYPE Rotary
WORKS WITH IOS Yes
WORKS WITH ANDROID Yes
UL LISTED Yes
CSA LISTED Yes
ETL LISTED Yes
AHRI CERTIFIED Yes
REGISTERED WARRANTY Extended Limited Lifetime*
BASE PARTS WARRANTY 1 Year
BASE COMPRESSOR WARRANTY 2 Years
CONTAINS CHEMICALS Yes
CONTAINS COMPRESSED GAS Yes
PROPOSITION 65 WARNING Yes
NET DEPTH (IN) 10.63
NET HEIGHT (IN) 19.49
NET WIDTH (IN) 28.35
NET WEIGHT (LBS) 54.89
GROSS DEPTH (IN) 10.63
GROSS HEIGHT (IN) 21.26
GROSS WIDTH (IN) 32.87
GROSS WEIGHT (LBS) 67.24



Air Handler Specifications

BRAND NAME MRCOOL
SERIES EasyPro 5th Gen
MODEL EZPRO-12-HP-WMAH-115D-O
GTIN 840255586771
UPC 840255586771
UNIT TYPE Mini-Split
EQUIPMENT TYPE Air Handler
SHORT DESCRIPTION EasyPro 5th Generation 12k BTU 115V Air Handler
CFM 353.2 / 294.3 / 235.4 / 176.6 / 129.5
TONNAGE 1
COOLING CAPACITY (BTU) 12000
HEATING CAPACITY (BTU) 12000
VOLTAGE (V) 115
PHASE 1
CYCLE 60
MAX FUSE BREAKER (A) 15
MIN CIRCUIT AMPACITY (A) 3
MOUNT TYPE Wall
COLOR White
MAX COVERAGE AREA 550 sqft
DECIBEL RATING (DBA) 35
DECIBEL RATING LOW (DBA) 17.5
DECIBEL RATING HIGH (DBA) 44.5
NUMBER OF SPEEDS 5
LIQUID LINE SIZE 1/4
SUCTION LINE SIZE 3/8
BLOWER MOTOR SPEEDS 3
BLOWER MOTOR RPM 850/750/450
FILTER TYPE Reusable
FAN ONLY OPTION Yes
SLEEP MODE Yes
AUTO COOL Yes
WIFI COMPATIBILITY Yes
APP COMPATIBILITY Yes
WORKS WITH IOS Yes
WORKS WITH ANDROID Yes
REMOTE CONTROL INCLUDED Yes
UL LISTED Yes
CSA LISTED Yes
ETL LISTED Yes
AHRI CERTIFIED Yes
REGISTERED WARRANTY Extended Limited Lifetime*
BASE PARTS WARRANTY 1 Year
BASE COMPRESSOR WARRANTY 2 Years
HAS BATTERIES Yes
CONTAINS ELECTRONICS Yes
CONTAINS CHEMICALS Yes
CONTAINS COMPRESSED GAS Yes
PROPOSITION 65 WARNING Yes
NET DEPTH (IN) 7.87
NET HEIGHT (IN) 11.61
NET WIDTH (IN) 31.57
NET WEIGHT (LBS) 24.91
GROSS DEPTH (IN) 17.95
GROSS HEIGHT (IN) 14.17
GROSS WIDTH (IN) 36.02
GROSS WEIGHT (LBS) 35.71

Owner Manual
