MRCOOL - DIY 5th Gen Easy Pro - 2 Ton / 24,000 BTU Ductless Mini Split Air Conditioner & Heat Pump - 18.9 SEER2 - R454B - 230V

by MRCOOL
SKU EZPRO-24-HP-23016D-O
PRICE MATCH GUARANTEE*: Found A Better Price? We'll Beat It! 877-606-9202 *Excludes ACIQ and MRCOOL Products.
EASY RETURNS: 30 Days Return Policy*
NO SALES TAX IN 48 STATES!
FREE SHIPPING: Free Shipping On Most Products!
TRADE & VOLUME DISCOUNTS: Call / Email or Chat for Details!

ADD TO CART FOR INSTANT SAVINGS!

$2,149.00
  • Amazon
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • Shop Pay
  • Visa

The MRCOOL EasyPro 5th Generation 24,000 BTU 230V Ductless Mini Split Heat Pump Complete System is designed to efficiently heat and cool spaces up to 1,050 square feet. This DIY-friendly system includes a 16-foot pre-charged Fast Connection® line set, eliminating the need for professional installation. With an impressive 18.9 SEER2 rating and 8.7 HSPF2-4 rating, it offers energy-efficient performance year-round.

What's Included

  • 1 x MRCOOL DIY 24K Easy Pro 5th Gen Condenser - EZPRO-24-HP-C-23016D-O
  • 1 x MRCOOL DIY 24K Easy Pro 5th Gen Air Handler - EZPRO-24-HP-WMAH-230D-O
  • 1 x 16 ft. 3/8 x 5/8 Line Set - DIY16-3858-O
  • 1 x MRCOOL Remote Control - 17317000A63435

Features

  • DIY Installation: The 16-foot pre-charged Fast Connection® line set simplifies the installation process, allowing homeowners to set up the system without specialized tools or training.
  • Smart Controls: Compatible with the SmartHVAC Controller App, enabling remote operation via smartphone and voice control through Amazon Alexa and Google Assistant.
  • Energy Efficiency: Achieves a SEER2 rating of 18.9 and an HSPF2-4 rating of 8.7, providing efficient performance and potential cost savings.
  • Quiet Operation: Operates at a low noise level of 61 dB(A), ensuring a peaceful environment.
  • Durable Design: Features a Gold Fin® corrosion-resistant condenser, ideal for coastal and high-humidity areas.
  • Low Ambient Cooling: Capable of cooling in outdoor temperatures as low as 5°F, making it suitable for server rooms and greenhouses.
  • Additional Features: Includes Follow Me® function, Sleep Mode, Auto Mode, Timer Mode, and refrigerant leakage detection for enhanced comfort and safety.

Specifications

Condenser Specifications

BRAND NAME MRCOOL
SERIES EasyPro 5th Gen
MODEL EZPRO-24-HP-C-23016D-O
GTIN 840255586757
UPC 840255586757
UNIT TYPE Mini-Split
EQUIPMENT TYPE Condenser
SHORT DESCRIPTION EasyPro 5th Generation 24k BTU 230V Condenser
SEER2 18.9
EER2 9.7
HSPF2-4 8.7
HSPF2-5 6.9
TONNAGE 2
COOLING CAPACITY (BTU) 24000
HEATING CAPACITY (BTU) 25000
VOLTAGE (V) 208/230
PHASE 1
CYCLE 60
MAX FUSE BREAKER (A) 20
MIN CIRCUIT AMPACITY (A) 19
COLOR White
ZONE CAPACITY 1
REFRIGERANT TYPE R-454B
REFRIGERANT VOLUME (OZ) 50.44
DECIBEL RATING HIGH (DBA) 61
INVERTER DC
MIN AMBIENT COOL (F) 5
LINESET INCLUDED Yes
LINE SET LENGTH 16ft
MAX LINESET LENGTH (FT) 164
LIQUID LINE SIZE 3/8
SUCTION LINE SIZE 5/8
COMPRESSOR MOTOR TYPE Rotary
WORKS WITH IOS Yes
WORKS WITH ANDROID Yes
UL LISTED Yes
CSA LISTED Yes
ETL LISTED Yes
AHRI CERTIFIED Yes
REGISTERED WARRANTY Extended Limited Lifetime*
BASE PARTS WARRANTY 1 Year
BASE COMPRESSOR WARRANTY 2 Years
CONTAINS CHEMICALS Yes
CONTAINS COMPRESSED GAS Yes
PROPOSITION 65 WARNING Yes
NET DEPTH (IN) 13.46
NET HEIGHT (IN) 26.5
NET WIDTH (IN) 35.04
NET WEIGHT (LBS) 95.9
GROSS DEPTH (IN) 15.67
GROSS HEIGHT (IN) 29.13
GROSS WIDTH (IN) 39.17
GROSS WEIGHT (LBS) 117.73



Air Handler Specifications

BRAND NAME MRCOOL
SERIES EasyPro 5th Gen
MODEL EZPRO-24-HP-WMAH-230D-O
GTIN 840255586795
UPC 840255586795
UNIT TYPE Mini-Split
EQUIPMENT TYPE Air Handler
SHORT DESCRIPTION EasyPro 5th Generation 24k BTU 230V Air Handler
CFM 729.9 / 547.4 / 400.2 / 329.6 / /
TONNAGE 2
COOLING CAPACITY (BTU) 24000
HEATING CAPACITY (BTU) 25000
VOLTAGE (V) 208/230
PHASE 1
CYCLE 60
MAX FUSE BREAKER (A) 15
MIN CIRCUIT AMPACITY (A) 3
MOUNT TYPE Wall
COLOR White
MAX COVERAGE AREA 1050 sqft
DECIBEL RATING (DBA) 40
DECIBEL RATING LOW (DBA) 21.5
DECIBEL RATING HIGH (DBA) 51.5
NUMBER OF SPEEDS 5
LIQUID LINE SIZE 3/8
SUCTION LINE SIZE 5/8
BLOWER MOTOR SPEEDS 3
BLOWER MOTOR RPM 1100/940/780
FILTER TYPE Reusable
FAN ONLY OPTION Yes
SLEEP MODE Yes
AUTO COOL Yes
WIFI COMPATIBILITY Yes
APP COMPATIBILITY Yes
WORKS WITH IOS Yes
WORKS WITH ANDROID Yes
REMOTE CONTROL INCLUDED Yes
UL LISTED Yes
CSA LISTED Yes
ETL LISTED Yes
AHRI CERTIFIED Yes
REGISTERED WARRANTY Extended Limited Lifetime*
BASE PARTS WARRANTY 1 Year
BASE COMPRESSOR WARRANTY 2 Years
HAS BATTERIES Yes
CONTAINS ELECTRONICS Yes
CONTAINS CHEMICALS Yes
CONTAINS COMPRESSED GAS Yes
PROPOSITION 65 WARNING Yes
NET DEPTH (IN) 9.21
NET HEIGHT (IN) 13.27
NET WIDTH (IN) 42.6
NET WEIGHT (LBS) 35.49
GROSS DEPTH (IN) 16.34
GROSS HEIGHT (IN) 12.4
GROSS WIDTH (IN) 45.47
GROSS WEIGHT (LBS) 49.6
