Panasonic - 18,000 BTU Multi 2-Zone Outdoor Condenser 22.5 SEER2 - 230V - R32
ADD TO CART FOR INSTANT SAVINGS!
ADD TO CART FOR INSTANT SAVINGS!
This Panasonic multi-zone outdoor condenser unit provides heating and cooling for 2 indoor units and cold climate heating operation down to -26 °C (-15 °F). Choose the optimum indoor wall units for each room from 5k - 18k Btu.
Please note this is an outdoor unit only, for full system operation this needs to be paired with an indoor unit.
| SKU | CU-2Z18ABUC |
|---|---|
| Indoor Unit |
CS-MXZ5AKUA, CS-MXZ7AKUA, CS-XZ Series & CS-Z Series (CS-XZ9AKUAW x2)* *Specs shown below are when used with outdoor unit indicated. |
| Outdoor Unit | CU-2Z18ABUC |
| Capacity Cooling (Btu/h) / KW | 18,000 (7,200 - 25,600) / 5.27 KW |
| Capacity Heating (Btu/h) / KW | 22,000 (5,800 - 29,800) / 6.45 KW |
| Outdoor Air Flow | 2025 CFM |
| SEER2 | 22.50 |
| HSPF2 - Region IV / Region V | 12.50 / 10.00 |
| Power Supply (V, Phase, Hz) | 208 / 230V, Single Phase, 60Hz |
| Power Input - Cooling (W) | 1.2 kW (360 - 2 kW) |
| Power Input - Heating (W) | 1.66 kW (320 - 2.48 kW) |
| Dimensions (Outdoor) (H x W x D) | 31-5/16" x 34-15/32" x 12-5/8" (795 x 875 x 320 mm) |
| Weight | 128 lbs (58 kg) |
